Power system
Engine model: ZS1100
Rated power: 15 horsepower (approximately 11.03 kw)
Rated speed: 2400 rpm
Fuel tank capacity: 12L
Fuel type: Diesel
Transmission system
Transmission type: [Manual]
Number of gears: 6 forward gears, 2 reverse gears
Walking system
Tire specification: front wheel 500/12, rear wheel 650/16
Wheelbase：938 mm
wheel-base: front wheel 860 mm, rear wheel 1200 mm
Overall dimensions
Length: 2380 mm
Width: 1025 mm
Height: 1230 mm
Overall weight: 510 kg
1 .The engine cannot start
Check if the fuel is sufficient and if the fuel switch is turned on. Check if the battery is fully charged and if the starting line is normal. Check if the spark plug is working properly.
2 .Lack of power
Check if the air filter is clogged, and clean or replace it if it is clogged. Check if the fuel filter is clogged and replace it if necessary. Check if the valve clearance of the engine is normal.
3 .Brake failure
Check if the brake fluid level is sufficient, and add brake fluid if it is not. Check if there is any leakage in the brake pipe, and if there is, repair it immediately. Check the wear of brake pads, and replace them if they are severely worn. If you encounter a complex fault, it is recommended to contact a professional repairman for repair in a timely manner.
