Powerful ZS1100 Diesel Engine for Efficient Farm Work
At the core of this walking tractor is the trusted ZS1100 single-cylinder horizontal water-cooled four-stroke diesel engine. It adopts direct injection combustion technology to achieve higher fuel efficiency and stable power output. The rated power reaches 11.03kW (15HP) under continuous 12-hour operation, while the 1-hour peak power hits 12.13kW (16HP), fully meeting heavy-duty tilling requirements. Designed with hand start mode, the engine works steadily without relying on electric power supply, which is perfect for remote rural areas with unstable power conditions. The condenser cooling system maintains proper working temperature during long-hour field operations, reducing overheating risks and extending engine service life.
Compact Structure & Excellent Off-Road Performance
The overall dimension of the 15HP walking tractor is 2680×960×1250mm, with a net weight of 340kg and total machine weight 350kg. Its compact layout enables easy passage in narrow farm plots, vegetable gardens and fruit orchards. Key chassis parameters ensure great terrain adaptability:
- Minimum ground clearance: 185mm to avoid scratching crops and uneven soil
- Adjustable wheel track: 580–600mm to fit different row spacing
- 00-12 deep-grip farm tires, with two tire pressure settings: 0.8–2.0 kgf/cm² for field cultivation and 1.4–2.0 kgf/cm² for transportation tasks. Four B1880 triangular belts guarantee stable power transmission between engine and working attachments.
Matched Double-Speed Rotary Tiller for Superior Soil Preparation
This walking tractor is pre-matched with a 90# 24-blade double-speed rotary tiller, the most commonly used attachment for land preparation. The double-speed design allows operators to switch tilling speed freely according to soil hardness, realizing thorough soil crushing, weed removal and soil leveling in one pass. Besides rotary tillers, the tractor can connect multiple farm implements including moldboard plough, ridger, seeder and farm trailer to complete ploughing, ditching, sowing, short-distance transportation and other jobs.
Core Advantages of the 15HP Walking Tractor
- Wide Application Scenarios: Suitable for dry land, paddy fields, hills, mountain terraces, vegetable farms and orchards.
- Easy Operation & Maintenance: Simple mechanical structure, intuitive control handles, spare parts are easy to source globally.
- Strong Cost Performance: Lower purchase and fuel cost compared with four-wheel tractors, suitable for small and medium-sized farms.
- High Flexibility: Lightweight body turns easily in small plots, solves the problem that large tractors cannot access narrow farmland.
Who Should Choose This 15HP Walking Tractor?
If you manage small farmland, run an orchard or vegetable garden, or provide local agricultural machinery service, this ZS1100 15HP walking tractor is a worthy investment. It replaces heavy manual labor, greatly improves farming efficiency and cuts long-term labor expenses.
Compared with outdated farming tools, modern diesel walking tractors help farmers boost productivity and harvest yields. When looking for durable walking tractors, power tillers or hand tractors, the 15HP ZS1100 model with rotary tiller is always a top choice for global agricultural buyers.
